K5
New film camera s16
Film camera K5
Crafted from high-grade D16T aluminum, the K5 camera is built with precision-milled components using advanced CNC machining. Every critical mechanism is constructed from metal and mounted on high-precision bearings, ensuring exceptional quality and a long-lasting lifespan for the K5.
Precision fps
Our bldc motor control system is based on the latest developments in the field of
vector control of brushless motors and is powered by a high-speed 32-bit ARM Cortex processor.
We use a brushless motor with a high-precision magnetic encoder. All this together provides high accuracy of speed stabilization and produces a stable image.
vector control of brushless motors and is powered by a high-speed 32-bit ARM Cortex processor.
We use a brushless motor with a high-precision magnetic encoder. All this together provides high accuracy of speed stabilization and produces a stable image.
К5 Preliminary technical data
Fps: 1 to 50 fps
Mirror Shutter: Manually adjustable to: 45, 90, 135, 144, 150, 172.8, 180 degrees
Film format: Super 16mm
Film gate: Super 16 only
Lens mount: 54 mm stainless steel PL-mount
Flange focal distance: 52.00 mm -0.01
Ground glass: 1200 grit surface, quartz glass, super16mm mask
Videoassist: Quickly replaceable, based on GoPro Hero 4 Black Edition, Micro hdmi output
Remote control: Radio control, FPS selection, film control, start/stop.
Spool: 100ft (R-90 Spool-16mm.), 200ft (R-100 Spool-16mm.)
Power input: 14 to 17 Vdc
Battery: 7.4V 5400mAh Lithium-ion 2S, charger Type-C
Mirror Shutter: Manually adjustable to: 45, 90, 135, 144, 150, 172.8, 180 degrees
Film format: Super 16mm
Film gate: Super 16 only
Lens mount: 54 mm stainless steel PL-mount
Flange focal distance: 52.00 mm -0.01
Ground glass: 1200 grit surface, quartz glass, super16mm mask
Videoassist: Quickly replaceable, based on GoPro Hero 4 Black Edition, Micro hdmi output
Remote control: Radio control, FPS selection, film control, start/stop.
Spool: 100ft (R-90 Spool-16mm.), 200ft (R-100 Spool-16mm.)
Power input: 14 to 17 Vdc
Battery: 7.4V 5400mAh Lithium-ion 2S, charger Type-C
